Numark NS4 FX Service Manual

....4 AL2-51-4403 TRANSISTOR 2N4403 PNP 1 Q207
....4 AL2-54-0138 Mosfet BSS138 N-CH 1 Q208
....4 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 2 C208,216
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 15
C210,211,212,213,217,218,219,220,224,
225,226,228,230,231,232
....4 CS105K5003X5R CCAP SMD 1uF 10% 50V 0603 X5R 1 C234
....4 CS105K5005X7R CCAP SMD 1uf/50V 10% 0805 X7R 1 C221
....4 CS106K1605X5R CCAP SMD 10uF/16V 10% 0805 X5R 3 C235,242,243
....4 CS106K1606X5R CCAP SMD 10UF/16V 10% 1206 X5R 1 C227
....4 CS121J5003NPO CCAP SMD 120pF/50V 5% 0603 NPO 2 C209,215
....4 CS181J5003NPO CCAP SMD 180PF 50V 5% 0603 NPO 8 C200,201,203,204,205,207,229,233
....4 CS225K1605X7R CCAP SMD 2.2uF/16V 10% 0805 X7R 2 C222,223
....4 DIPESD15VL1BA ESD Protection Diode 6 D200,201,202,203,204,205
....4 DISDB540C-13-F Schottky Barrier Rectifier Dio 1 D206
....4 DITVSNUP2201SM Transient Voltage Suppressol D 1 D207
....4 ECS10725FLE E CAP 100UF/25V 8*10MM SMD LOW 1 EC213
....4 ECS47635DLE ECAP 47UF/35V 6.3X5.7mm SMD 16
EC200,201,202,203,204,205,206,207,208
,209,210,211,214,215,216,217
....4 ECS47725GLE ECAP LOWESR 470UF/25V 10*10MM 1 EC212
....4 ICLTC3261EMSE IC LTC3261EMSE 1 IC204
....4 ICNJM4580M IC NJM4580M 5 IC200,201,202,203,205
....4 OTM21CC222R1H3 NETWORK EMI Suppression Filter 6 FIL200,201,202,203,204,205
....4 RS000004J06 RESISTOR 0 5% SMD 1206 1 R251
....4 RS001M10F03 RESISTOR 1M 1% SMD 0603 1 R260
....4 RS003K08F05 RESISTOR 3K 1% SMD 0805 6 R200,201,203,217,218,220
....4 RS003K10F03 RESISTOR 3K 1% SMD 0603 8 R252,253,254,255,259,261,262,263
....4 RS010010F03 RESISTOR 100 1% SMD 0603 1 R250
....4 RS010K08F05 RESISTOR 10K 1% SMD 0805 1 R216
....4 RS018K08F05 RESISTOR 18K 1% SMD 0805 2 R202,219
....4 RS022K08F05 RESISTOR 22K 1% SMD 0805 2 R234,240
....4 RS02K408F05 RESISTOR 2.4K 1% SMD 0805 4 R233,235,239,242
....4 RS047008F05 RESISTOR 470 1% SMD 0805 6 R204,212,221,229,236,241
....4 RS086610F03 RESISTOR 866 1% SMD 0603 3 R245,246,247
....4 RS100K08F05 RESISTOR 100K 1% SMD 0805 8 R207,209,215,224,226,232,238,244
....4 RS1K8208F05 RESISTOR 1.82K 1% SMD 0805 10
R205,206,208,214,222,223,225,231,237,
243
....4 RS1K8210F03 RESISTOR 1.82K 1% SMD 0603 2 R256,264
....4 RS3K7408F05 RESISTOR 3.74K 1% SMD 0805 2 R213,230
....4 RS47K510F03 RESISTOR 47.5K 1% SMD 0603 2 R248,249
....4 RS7K6808F05 RESISTOR 7.68K 1% SMD 0805 4 R210,211,227,228
....4 TR2SD2114KSM TRANSISTOR 2SD2114K NPN 6 Q200,201,202,203,204,205
....4 TRDMP3099L MOSFET DMP3099L P-CHAN 30V 3.8 1 Q206
....4 UH322522T-100K Choke Coil 10UH 1 L201
....4 UHACM2012900-2P Chock 90 0.4A 2.0X1.2mm 1 L204
....4 UHBLM18PG121SN1 Bead 120 ±25% 2A 0603 2 FB201,202
....4 UHRBBN5045A102M Wire Wound Chip Common Mode Ch 1 L202
...3 TWPC21C003C01T INPUT PCB SMT Assembly 1 -
....4 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 6 C300,301,302,303,304,305
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 4 C308,309,310,311
....4 CS181J5003NPO CCAP SMD 180PF 50V 5% 0603 NPO 2 C306,307
....4 DIPESD15VL1BA ESD Protection Diode 4 D300,301,302,303
....4 ECS10616B Capacitor Electrolytic 10uF/16V 5 EC301,303,304,305,306
....4 ECS22616B Capacitor Electrolytic 22uF/16V 2 EC300,302
....4 FCN2T1000402 FCN Dual Touch 90° SMD 1 FCN300
....4 ICNJM4580M IC NJM4580M 2 IC300,301
....4 RS010010F03 RESISTOR 100 1% SMD 0603 1 R304
....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 2 R308,313
....4 RS020K10F03 RESISTOR 20K 1% SMD 0603 1 R300
....4 RS022K10F03 RESISTOR 22K 1% SMD 0603 2 R301,306
....4 RS056010F03 RESISTOR 560 1% SMD 0603 3 R302,303,305
....4 RS06K210F03 RESISTOR 6.2K 1% SMD 0603 2 R309,314
