Numark NS4 FX Service Manual

....4 RS100K10F03 RESISTOR 100K 1% SMD 0603 4 R311,312,315,316
....4 RS1K8210F03 RESISTOR 1.82K 1% SMD 0603 2 R307,310
....4 UHBLM15BB121SN1 Bead 120 300mA ±25% 0402 4 FB300,301,302,303
...3 TWPC21C003D01T HP PCB SMT Assembly 1 -
....4 CS101J5005NPO HF CCAP SMD 100pF/50V 5% 0805 NPO 2 C401,402
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 4 C404,405,406,407
....4 CS220K5005X7R CCAP SMD 22pF/50V 10% 0805 X7R 2 C400,403
....4 DIPESD15VL1BA ESD Protection Diode 2 D400,401
....4 ECS22725FLE ECAP LOWESR 220/25V 8*10MM SMD 2 EC400,402
....4 ECS47635DLE ECAP 47UF/35V 6.3X5.7mm SMD-D 2 EC401,403
....4 FCN2T1000402 FCN Dual Touch 90° SMD 1 FCN400
....4 ICNJM4580M IC NJM4580M 2 IC400,401
....4 OTM21CC222R1H3 NETWORK EMI Suppression Filter 2 FIL400,401
....4 RS001K10F03 RESISTOR 1K 1% SMD 0603 2 R406,407
....4 RS006808F05 RESISTOR 68 1% SMD 0805 4 R402,404,410,412
....4 RS012K08F05 RESISTOR 12K 1% SMD 0805 2 R401,409
....4 RS033K08F05 RESISTOR 33K 1% SMD 0805 2 R400,408
....4 RS1K8208F05 RESISTOR 1.82K 1% SMD 0805 4 R403,405,411,413
....4 TR2SD2114KSM TRANSISTOR 2SD2114K NPN 2 Q400,401
....4 UHBLM18PG121SN1 Bead 120 ±25% 2A 0603 1 FB402
...3 TWPC21C003E01T MIC PCB SMT Assembly 1 -
....4 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 6 C500,501,502,503,504,506
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 4 C509,510,511,512
....4 CS121J5003NPO CCAP SMD 120pF/50V 5% 0603 NPO 1 C508
....4 CS153K5005X7R CCAP SMD 0.015uF/50V 10% 0805 2 C505,507
....4 DIPESD15VL1BA ESD Protection Diode 2 D500,501
....4 DISDBAT54SSM Diode BAT54S 30V 0.2A 1 D502
....4 ECS10616B Capacitor Electrolytic 10uF/16V 2 EC501,503
....4 ECS22616B Capacitor Electrolytic 22uF/16V 2 EC500,502
....4 ICNJM4580M IC NJM4580M 2 IC500,501
....4 RS010010F03 RESISTOR 100 1% SMD 0603 1 R504
....4 RS020K10F03 RESISTOR 20K 1% SMD 0603 1 R500
....4 RS022K10F03 RESISTOR 22K 1% SMD 0603 2 R501,508
....4 RS056010F03 RESISTOR 560 1% SMD 0603 3 R502,503,506
....4 RS075008F05 RESISTOR 750 1% SMD 0805 1 R509
....4 RS082508F05 RESISTOR 825 1% SMD 0805 1 R507
....4 RS130K08F05 RESISTOR 130K 1% SMD 0805 1 R510
....4 RS3K7408F05 RESISTOR 3.74K 1% SMD 0805 2 R505,512
....4 RS47K508F05 RESISTOR 47.5K 1% SMD 0805 1 R511
....4 UHBLM15BB121SN1 Bead 120 300mA ±25% 0402 2 FB500,501
...3 TWPC21C003F01T Left Assign PCB SMT Assembly 1 -
....4 TE682000501 Pin Header 90° Pitch:2.0mm 1 (TE14)
...3 TWPC21C003G01T Right Assign PCB SMT Assembly 1 -
....4 TE682000501 Pin Header 90° Pitch:2.0mm 1 (TE15)
..2 TWPC21C003A01 Main PCB DIP Assembly 1 87
...3 SWDC11B2020469 Switch Rotational Encode 20Pul 1 ENC2
...3 SWDC11B2021431 Switch Rotational Encode 20Pul 1 ENC1
...3 VRR10301701 VARIABLE 10KB 7 VR1,8,14,15,17,24,30
...3 VRR10301704 Poltertiomaeter Rotary Volume 16
VR2,3,4,5,9,10,11,12,18,19,20,21,25,26,2
7,28
...3 VRR10301720 Potentiometer Rotary Volume 2 VR7,16
...3 VRS10304518 Potentiometer Slide 10K Trav 1 VR31
...3 VRS10304525 Potentiometer Slide 10K2B Trav 4 VR6,13,22,29
...3 VRS10310024 Potentiometer Slide 10K1B 100m 1 VR23
..2 TWPC21C003B01 USB PCB DIP Assembly 1 29
...3 JK0SCU201RFNO USB Connector 1 USB200
...3 JKANC3MAH XLR JACK 3Pin 90° Male 2 JK200,201

Numark NS4 FX Specifications

General

Brand	Numark
Model	NS4 FX
Category	DJ Equipment
Language	English
