Numark NS4 FX Service Manual

...3 JKDJ-0702B-020 DC Base 2.0MM 1 JK203
...3 MT11044128 Fixed Plate 1 MT200
...3 RJ1039-09-0580B RCA Jack(One Output) 1 JK202
...3 SWSPPJ22ME04 Switch Push 2P2T Dual Row Lock 1 SW200
...3 TE10200502 Connector (5P Socket)180° 1 (TE205)
...3 TE10200601 Connector in Header 180° Pitc 1 (TE201)
...3 TE10200602 Pin Header 90° Pitch:2.00mm 2 (TE200,203)
...3 TE622000302 Pin Header 90° Pitch:2.00mm 1 (TE206)
...3 TE622000501 Socket 5P 90° 1 (TE204)
...3 TE622000901 Pin Header 90° Pitch:2.00mm 1 (TE202)
..2 TWPC21C003C01 INPUT PCB DIP Assembly 1 27
...3 JK6631501070 Bahf Base W/NUT 6.3 1 JK300
...3 RJ1039-09-0580B RCA Jack(One Output) 1 JK301
...3 TE612000801 Connector 8P 180° 1 (TE300)
..2 TWPC21C003D01 HP PCB DIP Assembly 1 75
...3 JK-3537 3.5mm Phone Jack 9P 90° DIP F 1 JK400
...3 JY6317-02-030 Earphone base W/NUT 1 JK401
...3 TE622000401 Pin Header 90° Pitch:2.00mm 1 (TE400)
..2 TWPC21C003E01 MIC PCB DIP Assembly 1 74
...3 JK6631501070 Bahf Base W/NUT 6.3 1 JK500
...3 TE622000501 Socket 5P 90° 1 (TE500)
...3 VRR10301567 Potentiometer Rotary 10K15A 15 1 VR501
...3 VRR50201511 Potentiometer Rotary Volume:5K 1 VR500
..2 TWPC21C003F01 Left Assign PCB DIP Assembly 1 73
...3 SWSKV-23D21 SWITCH 2 S1,2
..2 TWPC21C003G01 Right Assign PCB DIP Assembly 1 72
...3 SWSKV-23D21 SWITCH 2 S3,4
..2 TWPC21C003H01 Left Toggle SW PCB DIP Assembl 1 54
...3 SWLBCR23M-095A Switch Toggle dual Row 3Pulse 1 SW1
...3 TE622000302 Pin Header 90° Pitch:2.00mm S 1 (TE6)
..2 TWPC21C003I01 Right Toggle SW PCB DIP Assemb 1 55
...3 SWLBCR23M-095A Switch Toggle dual Row 3Pulse 1 SW2
...3 TE622000302 Pin Header 90° Pitch:2.00mm 1 (TE9)
0.1 TWPC21C00401 Function PCB Assembly 1 86
..2 TWPC21C00401T Function PCB SMT Integration A 1 -
...3 PC21C004 Function PCB 1 -
...3 TWPC21C004A01T Left Function PCB SMT Assembly 1 -
....4 AA822524X IC SN74HC165PW 3 IC2,4,6
....4 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 3 C4,9,14
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 11 C1,2,6,7,11,12,16,19,21,22,23
....4 CS105K1603X7R CCAP SMD 1uF/16V 10% 0603 X7R 1 C18
....4 CS475K1605X5R CCAP SMD 4.7uF/16V 10% 0805 X5R 1 C17
....4 CS561J5003NPO CCAP SMD 560pF/50V 5% 0603 NPO 3 C5,10,15
....4 DICM1213A01SO Diode ESD Protection Arrays 1 D1
....4 ECS22716D8LE ECAP LOW ESR 220uF/16V 2 EC1,2
....4 FCN2T1001001 FCN Dual Touch 180° SMD Pitch 1 FCN1
....4 IC74AHC1G14DBVR IC 74AHC1G14DBVR 1 IC8
....4 IC74HCT595D IC 74HCT595D 3 IC1,3,5
....4 LDKPT-1608SURCK Liquid-emitting Diode Red SMD 4 LED1,2,3,4
....4 LDL-S291SWC-ML5 LED White SMD 0603 120° 17
LED7,8,9,10,11,12,13,14,15,16,17,18,19,
20,21,22,23
....4 LDLTST-C193TGKT Liquid-emitting Diode Green SMD 2 LED5,6
....4 RS003310F03 RESISTOR 33 1% SMD 0603 9 R16,19,21,26,37,39,46,49,50
