Numark NS4 FX Service Manual

....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 23
R1,2,3,4,5,6,7,8,28,29,30,31,32,33,34,35,
51,52,53,54,55,56,57
....4 RS012010F03 RESISTOR 120 1% SMD 0603 12 R17,18,20,22,23,24,25,27,36,38,40,41
....4 RS01K210F03 RESISTOR 1.2K 1% SMD 0603 6 R9,10,11,12,13,15
....4 RS02K410F03 RESISTOR 2.4K 1% SMD 0603 5 R43,44,45,47,48
....4 RS04R704F06 RESISTOR 4.7 1% SMD 1206 1 R59
....4 RS49R910F03 RESISTOR 49.9 1% SMD 0603 4 R14,42,58,60
....4 SWEVQ11L05R Switch Tact 5mm 160g Horizonta 11 SW13,14,15,16,17,18,19,20,21,22,23
....4 UH160808T-600Y BEAD 60 @100MHz 3A ±25% 0603 4 L1,2,3,4
....4 UHBLM18PG121SN1 Bead 120 ±25% 2A 0603 2 L5,6
...3 TWPC21C004B01T Left LCD PCB SMT Assembly 1 18
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 4 C201,203,204,206
....4 CS104K5005X7R CCAP SMD 0.1uF/50V 10% 0805 X7R 1 C208
....4 CS105K5003X5R CCAP SMD 1uF 10% 50V 0603 X5R 2 C200,207
....4 CS106K1605X5R CCAP SMD 10uF/16V 10% 0805 X5R 2 C202,205
....4 FCN1T1001001 FCN Down Touch Pitch 1.0mm 1 FCN200
....4 RS000010J03 RESISTOR 0 5% SMD 0603 1 R207
....4 RS002004F06 RESISTOR 20 1% SMD 1206 1 R200
....4 RS010010F03 RESISTOR 100 1% SMD 0603 1 R206
....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 2 R203,204
....4 RS04K710F03 RESISTOR 4.7K 1% SMD 0603 2 R201,202
....4 TE681250201 Box Header 90° 1.25mm Single 1 (TE200)
....4 TE681250601 Box Header 90° 1.25mm Single 1 (TE201)
....4 UH160808T-601Y CAPACITOR 2 L200,201
...3 TWPC21C004C01T Right LCD PCB SMT Assembly 1 19
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 4 C301,303,304,306
....4 CS104K5005X7R CCAP SMD 0.1uF/50V 10% 0805 X7R 1 C308
....4 CS105K5003X5R CCAP SMD 1uF 10% 50V 0603 X5R 2 C300,307
....4 CS106K1605X5R CCAP SMD 10uF/16V 10% 0805 X5R 2 C302,305
....4 FCN1T1001001 FCN Down Touch Pitch 1.0mm 1 FCN300
....4 RS000010J03 RESISTOR 0 5% SMD 0603 2 R307,308
....4 RS002004F06 RESISTOR 20 1% SMD 1206 1 R300
....4 RS010010F03 RESISTOR 100 1% SMD 0603 1 R306
....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 1 R303
....4 RS04K710F03 RESISTOR 4.7K 1% SMD 0603 2 R301,302
....4 TE681250201 Box Header 90° 1.25mm Single 1 (TE300)
....4 TE681250601 Box Header 90° 1.25mm Single 1 (TE301)
....4 UH160808T-601Y CAPACITOR 2 L300,301
...3 TWPC21C004D01T Left Sensor PCB SMT Assembly 1 -
....4 AA822748X Diode BAV99 1 D401
....4 AL2-51-4401 TRANSISTOR 2N4401 NPN 2 Q400,401
....4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 4 C400,402,404,405
....4 DIEN1N4148WSM HF Diode 1N4148 SOD123 SMD 1 D400
....4 DIENMMBD4148SE Diode Single MMBD4148SE 100V 2 1 D402
....4 DITPD1E04U04DPY Transient Voltage Suppressor 1 D403
....4 IC74LVC2G17DBV IC 74LVC2G17DBV 1 IC400
....4 ICLM393DR IC OPA LM393DR 1 IC401
....4 RS010K10F03 RESISTOR 10K 1% SMD 0603 5 R401,402,407,409,410
....4 RS033210F03 RESISTOR 332 1% SMD 0603 2 R406,412
....4 RS056010F03 RESISTOR 560 1% SMD 0603 2 R403,408
....4 RS12K110F03 RESISTOR 12K1 1% SMD 0603 1 R400
....4 RS22K110F03 RESISTOR 22.1K 1% SMD 0603 2 R405,411
....4 RS49K910F03 RESISTOR 49.9K 1% SMD 0603 1 R404
....4 TE682000602 Pin Header 90° Pitch:2.0mm 1 (TE400)
....4 TR2SK1828 Mosfet N-CH 20V MAIN 2-Pin 1 Q402
....4 UHBLM18PG121SN1 Bead 120 ±25% 2A 0603 2 L400,401
...3 TWPC21C004E01T Right Sensor PCB SMT Assembly 1 -
....4 AA822748X Diode BAV99 1 D501
....4 AL2-51-4401 TRANSISTOR 2N4401 NPN 2 Q500,501
