Numark TT-1510 - Parts Description; Assembly

TT1510
- The Leader in DJ Technology
©2000 Industries - 4 - http://www.numark.com
CENTER SPINDLE
PARTS DESCRIPTION
1. 45-rpm Adapter
2. Anti-static slip mat
3. Center Spindle
4. Stroboscope
5. Start/Stop Button
6. Speed Select Button
7. Strobe Dots
8. Adjustable Feet
9. Power Button
10. Headshell
11. Pitch Control Slider
12. Tonearm
13. Arm Rest
14. Cueing Lever
15. Anti-skating Knob
16. Counterweight
17. Hinge For Dust Cover
18. Belt Drive Spindle
ASSEMBLY
1. Remove the main unit with the packing from the box and take off the packing material.
DO NOT DISCARD ANY PACKING MATERIAL. The headshell, counterweight, and other parts are
contained within the packing material.
2. Set the 45-rpm adapter on the main unit.
3. Set the voltage selector switch to the 110-127 or 220-240V position according to the voltage of power supply.
(This unit has been preset for 110-127V AC).
4. Insert the turntable platter onto the center spindle.
