OPERATING INSTRUCTIONS
1. Push the power button to turn on the power, the speed
indicator and the strobe-illuminator will light up.
2. Place a record on the turntable mat, when playing a 45rpm
record with a large center hole, place the 45-rpm adaptor
on the center spindle.
3. Set the rotation speed (33/45) to match the record.
4. Remove the stylus protector, release the arm clamp.
5. Set the cueing lever to the up position.
6. Press the Start/Stop button, the turntable platter will start to
rotate.
7. Move the tonearm over the desired groove.
8. Set the cueing lever to the down position, the tonearm will
descend slowly onto the record and play begins.
9. To suspend play, lift tone arm with cueing lever.
10. When play is finished,raise the cueing lever, move the
tonearm to the arm rest, secure the tonearm with the arm
clamp .
11. Press the Start/Stop button to stop the platter rotating,
push the power button to turn off the power.
TARGET LIGHT
This unit is provided with a target light for illuminating the
stylus tip during play. Push the target light button, the
target light will be raised into position for illuminating the
stylus tip. When not in use, keep the target light lowered
through depression.
PITCH ADJUSTMENT
The pitch control is variable in a range of +/- 10%. During play,
observe the strobe dots, if the strobe dots appear to the
right, the pitch is slower than the rated speed, if flow to the
left, the pitch is faster than the rated speed, if the strobe
dots appear stationary, which means the platter is in
normal turntable speed. Move the pitch control slider up or
down to adjust the speed.
PLACEMENT
•Do not place the unit in a location where it will be exposed
to direct sun light or near a heating appliance.
•Do not place the unit in a location where there is high
humidity or a lot of dust.
•Cartridge may pick up slight sound pressure or vibrations of
the speakers coming along the floor or through the air
resulting in howling. Find a location which is very stable
and free vibration.
•The legs have functions for adjusting the height of the unit
itself. Adjust the legs to stabilize the main body
horizontally.
MAINTENANCE
•Clean the stylus periodically with a soft brush to prevent the
accumulation of dust.
•When the sound becomes distorted or noisy, check the
stylus. If worn out, replace it with a new one.
•From time to time, the dust cover and turntable cabinet
should be wiped with a soft, dry cloth. Any volatile
materials as alcohol,thinner, benzine, etc.,may remove the
paint or damage the luster, should not be used.
SPECIFICATIONS
Turntable section
Type 2-speed, full manual
Driving method Belt drive
Motor DC motor
Turntable platter Aluminum diecast 330mm dia.
Turntable speed 33-l/3 and 45 rpm
Starting torque more than 650g-cm
Wow and flutter Less than 0.25%
S/N ratio 50dB (DIN-B)
Tonearm section
Type Universal s-shaped tubular arm
Effective length 220mm
General
Power supply AC110-127V/220-240V,50/60Hz
Power consumption 8 Watts
Dimension(WxDxH) 450 x 350 x 148 mm
17 3/4” x 13 3/4” x 5 7/8”
Weight 6.5 Kgs 14 lbs
Specifications and design may be changed without notice for
improvement.
