Numatics DPS280 Series User Manual

Mounting Bracket Kits
Panel Mounting Kit
0.157
(4.0)
1.35
(34.4)
1.35
(34.4)
1.30
(33.0)
1.19
(30.2)
1.30
(33.0)
1.19
(30.2)
0.335
(8.5)
1.35
(34.4)
1.35
(34.4)
Panel adapter
(Rear)
Panel adapter
(Rear)
Panel adapter
(Front)
Panel adapter
(Front)
Protective cover
(Front)
Protective cover
(Front)
(31 × 31 + 0.0 /
- 0.4)
1.22 × 1.22 + 0.0 /
- 0.016
(t ≤ 4.5)
t ≤ 0.177
(2 M3 Screws Included)
(Includes 2 adapters & 1 cover)
PMK280-C
Units: Inch
(mm)
0.24
(6.1)
0.20
(5.0)
0.79
(20.0)
0.16
(4.2)
0.51
(13.0)
0.50
(12.9)
1.46
(37.1)
M3
Mounting bracket L TYPE
M3
Mounting bracket S TYPE
BRK280-1 BRK280-2
1.79
(45.5)
1.03
(26.2)
0.20
(5.0)
0.98
(25.0)
0.16
(4.2)
Units: Inch
(mm)
DIMENSIONS
1.0
(25.4)
1.18
(30.0)
(150±10)
1/8 NPT Male x 10-32 UNF Female
1/8 PT x M5
G 1/8 x M5
M8 Female 4 Pin Mating Cable Supplied With Switch
Cable O.D. - 4.0mm
Conductor Gauge - 26 AWG
Mating Cable:
0.46
5.9±0.4
(11.8)
1.26¨
78.75¨
0.28¨
0.35¨
(32)
(7)
(9)
(2000 mm)
Units: Inch
(mm)
(30.0)
(30.0)
1.18
1.18
HEX
M3 x 0.5 THD
2 PLS
(20.0)
0.79
(10.0)
0.39
(10.0)
0.39
(20.0)
0.79
(11.0)
7/16¨
DPS280 / DVS280 Series
3
