11 MIXX Pushchair Instructions 12MIXX Pushchair Instructions
EN
EN
Product Set Up
Open Pushchair
1 - Pull the storage latch out. (1)
2 - Rotate the handle to the rear of the pushchair. A “click”
sound means the pushchair frame is open completely.
(2)
3 - Squeeze the recline adjustment button on the back of
the seat and rotate the backrest to the upright position.
(3)
Check that the pushchair is open completely before
continuing.
Canopy
1 - Zip the canopy visor to the inside of the canopy. (4)
2 - Insert the canopy clips into the canopy mounts on
the sides of the pushchair. A “click” sound means the
canopy is assembled completely. (5)
Front Wheels
1 - Insert the front wheel into the front leg. A “click” sound
means the wheel is assembled completely. (6) Repeat
on opposite side.
Check the wheel is securely attached by pulling out.
2 - To remove the front wheel, press the release button (7)-1
and detach the front wheel from the front leg. (7)-2
Brake Assembly
Make sure the brake lever is facing up before attaching the
brake assembly to the frame.
1 - Push the brake assembly onto the rear leg tubes. A
“click” sound means the break assembly is attached. (8)
Check that brake assembly is securely attached by
pulling out.
Rear Wheels
1 - Insert the rear wheel into the rear leg. A “click” sound
means the rear wheel is assembled completely. Repeat
on opposite side. (9)
Check that the wheels are securely attached by pulling
them out.
2 - To remove the rear wheel, press the release button (10)-1
and detach the rear wheel from the rear leg. (10)-2
Storage Basket
1 - Wrap the basket flap around the rear frame and fasten
the 3 snaps on the basket. (11)
Armbar
Always secure the child with the harness. The armbar is
not a restraint device.
1 - Align the armbar ends with the armbar mounts, and
insert until it clicks into place. A “click” sound means
the armbar is assembled completely. (12)
To Next Page
