Seat Pad
The seat pad can be removed to provide a mesh seating
area for better ventilation during hot weather.
Remove the canopy before removing the seat pad.
1 - To remove the seat pad, unsnap the seat pad from the
back of the seat. (22)
2 - Then, unbuckle the harness, thread the harness through
the harness slots and remove the seat pad. (23)
DO NOT remove the backrest tube.
Front Swivel Locks
It is recommended to use the front swivel locks on uneven
surfaces.
1 - To lock the front wheels, press down on the swivel lock.
The lock will engage when the wheel is straight. (24)
2 - To unlock the front wheels, pull up on both swivel locks.
(25)
Brake
1
- To lock the rear wheels, step down on the brake lever.
(26)
2 - To unlock the rear wheels, lift up on the brake lever. (27)
Always apply the brake when the stroller is stopped.
Push the stroller slightly to ensure the brake is engaged.
Canopy
Fully extend the handle for canopy use.
1 - To open the canopy, pull the canopy toward the front of
the seat. To close the canopy, push it back. (12)
2 - Position the canopy visor forward or backward as
needed. When not in use, fold the canopy visor under
the canopy. (13)
3 - Open the zipper (14) on the canopy to use the dream
drape™.
4 - Pull down on the dream drape™ for extra shade. (15)
5 - To detach the canopy, pull in on the canopy mounts to
remove them. (16)
6 - Unsnap the canopy from the back of the seat and
remove the canopy. (17)
To reattach the canopy, reverse these steps.
Calf Support
The calf support has 2 use positions.
1 - To raise the calf support, lift up. (18)
2 - To lower the calf support, press the adjustment buttons
on both sides (19)-1, and push down (19)-2.
Recline
There are 2 zippers on each side of the seat back for
2 recline positions.
1 - For recline position 1, unzip the outer zippers. (20)
2 - For recline position 2, unzip the inner zippers. (21)
13 PEPP next instructions 14PEPP next instructions
