Calf Support
The calf support has 2 use positions.
1 - To raise the calf support, lift up.
2 - To lower the calf support, press the adjustment buttons
on both sides (1), and push down (2).
Recline
There are 2 zippers on each side of the seat back allowing
for 3 recline positions.
For recline position 1, both zippers remain zipped.
3 - For recline position 2, unzip the outer zippers.
4 - For recline position 3, unzip the inner zippers.
Seat Pad
The seat pad can be removed to provide a mesh seating area
for better ventilation during hot weather.
Remove the canopy before removing the seat pad.
5 - To remove the seat pad, unsnap the seat pad from the
back of the seat.
6 - Then, unbuckle the harness, thread the harness through
the harness slots and remove the seat pad.
DO NOT remove the backrest tube.
12
6
1 4
52
3
18 PEPP next instructions 19PEPP next instructions
