Nuna PIPA LITE R User Manual

PIPA RELX
™
Base
Parts List
Make sure all parts are available
before assembly. If any part is
missing, please contact Nuna
(see page 5 for information).
No tools are required for assembly.
3
2
5
4
6
12
11
10
9
11
13
10
14
15
1
1 Rigid Latch Guides
2 Vehicle Belt Lock Off
3 Lock Off Release Button
4 Belt Positioner
5 Rigid Latch (Lower Anchors)
6 Rigid Latch Release Button
7 Recline Indicator Window
8 Recline Adjustment Button
9 Child Restraint Release Button
10 Stability Leg
11 Stability Leg Adjustment Button
12 Stability Leg Indicator
13 Stability Leg Storage Release
Button
14 Stability Leg Storage
15 Instruction Manual Storage
(under Stability Leg)
8
7
18 PIPA lite r instructions 19PIPA lite r instructions
