Recline Adjustment
(continued)
Check the Installation
After recline adjustment, check
that the child restraint is still
securely attached to the base by
pulling up on the handle.
Releasing Child Restraint
from PIPA RELX
™
Base
1
- To release the child restraint,
squeeze the child restraint
release button (1) located on
the base, then pull the child
restraint up (2).
Uninstalling PIPA RELX
™
Base
When Installed with Rigid Latch:
2 - Squeeze the rigid latch release
buttons.
3 - Pull the base off of the bars.
4 - Rotate the rigid latch back into
storage position.
When Installed with Lap and
Lap/Shoulder Belt:
5 - Lift the lock off release button.
6 - Unbuckle the vehicle belt and un-
route the shoulder and lap belt
from the base. Remove the base.
2
1
1
2
3
4
5
6
50 PIPA lite r instructions 51PIPA lite r instructions
