17
2 Position base in a forward
facing vehicle seat. Use recline
adjustment to position bubble
in indicator. Adjust base so
bubble touches line.
3 Use recline adjustment to achieve
correct angle for installation
4 Recline adjustment
locks into position.
To release press down
on lock button.
5 When installing with the base,
additional stability can be achieved
by using the stability leg. For
instructions on using the
stability leg when installing the base,
see stability leg section. (Page 22)
6 If necessary, install plastic
connector guides on vehicle LATCH
lower anchor bars.
7 Hook Rigid LATCH (lower attachments)
onto vehicle LATCH lower anchor bars.
Confirm proper installation by pulling
on the base AND also seeing that green
is indicated on the connectors.
