Nuna Pipa User Manual

18
The Rigid LATCH (lower attachments)
must be attached and
locked ontothe vehicle
anchor points.
8 Check the installation.
a) Base should not move side to
side or forward more than 1”
at belt path.
b) Bubble must be touching line.
Use recline adjustment, if needed,
to position bubble.
• It is safe to install with both LATCH
(lower attachments) and the vehicle
belt.
9 After child is properly secured
in carrier, press carrier on base
and listen for a click. Pull on
carrier to verify installation.
DO NOT allow carrier to contact interior of
vehicle.
Your child may not be protected in the event

Nuna Pipa Specifications

General

Product color	Red
Car seat group	0+ (0 - 13 kg; 0 - 15 months)
Side protection	Yes

Weight and Dimensions

Depth	700 mm
Width	435 mm
Height	530 mm
Weight	3950 g
