SPECIFIC SAFETY INSTRUCTIONS
This machine must be firmly secured to a suitable workbench or
otherstableworksurface.
Whenselectingasuitablelocationfor mounting this machine
consideration must be given to the maximum length of the
material to be drilled or machined and the position of the
operator.
Before starting the machine ensure that drills and other
recommended cutting tools are fitted correctly, that all the
securing bolts are tight and all guards are fitted and are operating
correctly and that the chuck key and any other adjustment tools
havebeenremoved.
Keep hands well away from rotating drills and other cutting tools
atalltimes.
When drilling use the correct cutting lubricant/coolant for the
material being drilled. Use only sufficient to prevent the drill
from overheating and make sure that it is kept well away from
electricalcomponents.Neverusewaterasacoolant.
Keep drills, and other cutters sharp and in good condition.
This will improve cutting and reduce the load on the Machine
ensuringalongerlifeofthecuttingtoolsandthemachine.
Use only drill bits, cutters and other accessories recommended
bythemanufacturer.
Selectthecorrectspindlespeedforthesizeofdrillbeingused.
Seetheinstructionmanual.
Do not attempt to modify the machine or its accessories in
anyway.
Do not force the machine let the machine do the work this will
reduce the wear on the machine and cutter and increase its
efficiencyandoperatinglife.
Use approved safety glasses or goggles, face mask and Ear
defenderswhenusingforprolongedperiods.
Whendrillinglonglengthsensurethatthereisadequatesupport
atbothendsofthematerial.
Never use the machine without the safety guards in position and
operatingcorrectly.
Ensure that the work piece is free from any nails or other foreign
objectsthatcoulddamagethedrillsandothercuttingtools.
Alwayssecuretheworkpieceinasuitabledrillvice.Nevertry
andsecuretheworkpiecewithyourhands.
Warning: Be aware that swarf can be very sharp and hot and
canflyofftherotatingdrill.Whenhandlingswarfalwayswear
suitablegloves.Swarfshouldnotbedisposedofwithdomestic
waste,itshouldbedisposedofatarecyclingcentre.
Neverleavethemachinerunningwhileunattended.
Always allow the machine to come to a complete stop and
disconnect from the power supply before leaving the unit
unattended.
NOTE: This manual covers the assembly and operation of
both workbench and floor mounted drilling machines. These
instructions can be used for both types of machine, the only
variation being the location and mounting of the drilling machine
eitheronaworkbenchorontothefloor.
COMPONENTS AND CONTROLS (PIC. 1)
UNPACKING SAFETY
The items marked with an * should be checked off when
unpackingthisproduct.
UNPACKING
Caution! This packaging contains sharp objects. Take care
when unpacking. This machine could require two persons to
lift, assemble and move this machine. Remove the machine,
together with the accessories supplied, from the packaging.
Check carefully to ensure that the machine is in good condition
andaccountforalltheaccessorieslistedinthismanual.Also
makesurethat all theaccessoriesarecomplete.If any parts
are found to be missing, the machine and its accessories should
bereturnedtogetherintheiroriginalpackagingtotheretailer.
Do not throw the packaging away, keep it safe throughout the
guarantee period, then recycle if possible, otherwise dispose
ofitbythepropermeans.Donotletchildrenplaywithempty
plasticbagsduetotheriskofsuffocation.
LOCATING THE MACHINE
When determining where to locate or permanently fix the
machine,considerationmustbegiventothefollowingpoints.
Isthereasuitablemainsoutletsocketnearby.Ifthemachine
is to be permanently mounted onto a bench is the bench at a
suitable height and is it strong and stable enough to carry the
weightofthemachine.
1 Induction motor 9 RackupperretainingCollar
2 Drive belt guards 10 Racktoallowtabletoberaisedorlowered
3 Start/Stopwithemergencystop 11* Handle to adjust table
4* Telescopic eye guard 12* Column support
5* Chuck 13* Base casting
6* Handle 14 Locking knob
7* Adjustabletable 15 Belt tension lever
8* Securing handle 16* Chuck, drift and 2 hexagonal keys
