12
Depth Measurement Guidelines
Reference Plane:
- The front edge of module has been used as the reference plane for calibration of
KHKT001-EVM, so all measurements taken by KHKT001-EVM are values of distance
(in mm) from this front edge.
Refer to the figure below:
KHKT001
-EVM
Emitter
Measured Distance
Target Object
Reference Plane
