nuwavenow.com | 15
CLEANING & MAINTENANCE
To clean the surface underneath the
Inner Vent Screen.
1. Turn the OxyPure off and unplug it from
the wall outlet.
2. Lift the Top Vent using the built-in tab.
3. Using a vacuum with a brush
attachment or duster, clean any dust or
accumulated particles from the surface
an Inner Vent Screen.
To clean the inner wall opposite of the
fan or to remove an object that has fallen
through the Inner Vent Screen.
1. After removing the Top Vent, locate the
two screws at the top of each side of
the vent.
2. Use a Phillips screwdriver to loosen
only the two screws shown on the
diagram to the right. Be sure to set in a
secure location.
3. Lift up the Inner Vent Screen.
4. After cleaning the inner wall with
a soft cloth or paper towel, or
duster. Reassemble the Inner Vent,
retightening the two screws, and
replace the Top Vent.
• Make sure all parts are secure
before plugging in the OxyPure and
turning it on again.
Note: DO NOT unscrew the four outer screws located toward the corners. Doing so will
void your warranty.
DO NOT immerse the OxyPure in water. Clean with a damp sponge or cloth and
wipe dry. Make sure all parts and covers are securely attached.
Cleaning the Top Vent
The Top Vent of your OxyPure can be removed to clean with a vaccum with a brush
attachement or cleaned in mild soapy water and dried thoroughly.
ODOR
NO
ODOR
STRONG
ODOR
CLEAN FILTER 2/3
AIR
SLEEP MODE
AUTO
ULTIMATE
CLEAN
FAN
SPEED
TIMER TURBO
HR CLEAN DIRTYHRHIGHLOW
WIFI
ECO MODE
WIFI
RESET FILTER
Cleaning the Odor Sensor Opening
The Odor Sensor is located on the upper right side corner of the
OxyPure underneath the small grill opening.
• Keep the Odor Sensor clear of dust and debris by cleaning with
a vacuum brush attachment.
• DO NOT tamper or spray inside or near the odor sensor. This
may cause the sensor to malfunction and will void the warranty.
Odor Sensor
