Interface Description
Memory
6
NC-SI
Management
Interface
Connection for remote sideband management
7
USB 4-pin
vertical
connector
(default)
Mounted on the DPU for OS image loading
8
1GbE OOB
Management
Interface
1GbE BASE-T OOB management interface
9 RTC Battery Battery holder for RTC
10
eMMC
Interface
x8 NAND flash
FHHL DPU Layout and Interface Information
Interfaces of MBF2H516A-EEEOT, MBF2H516A-EENOT, MBF2M516A-EECOT,
MBF2M516A-EEEOT and MBF2M516A-EENOT
Component Side Print Side
