LED Indications Link Activity
OFF OFF Link off Link off
ON OFF 1 Gb/s link / No activity
Link on (any speed *) / No
activity
Blinking OFF
1 Gb/s link / Activity
(RX,TX)
1 Gb/s link / Activity (RX,TX)
OFF ON
Not supported
100 Mb/s link / No activity
OFF Blinking 100 Mb/s link / Activity (RX,TX)
ON ON 10 Mb/s link / No activity
Blinking Blinking 10 Mb/s link / Activity (RX,TX)
* On DPUs without BMC, speeds can be 10 Mb/s, 100 Mb/s or 1Gb/s.
External PCIe Power Supply Connector
Warning
Applies to FHHL P-Series DPUs only, OPNs MBF2H516A-CEEOT and
MBF2H516A-CENOT.
Important
FHHL P-Series DPUs require supplementary power from a 6-pin ATX
power supply connector in addition to a minimum of 75W power
