NVIDIA BlueField-2 InfiniBand/Ethernet DPU User Guide 47
The below table lists the motherboard and power supply requirements per card form
factor.
HHH
L
DPU
s
E-Series: A maximum of 75W system power supply through the PCIe x16
interface (Relevant for MBF2M345A-HECOT and MBF2M345A-HESOT)
FHH
L
DPU
s
E-Series: A maximum of 75W system power supply through the PCIe x16
interface (Relevant for MBF2M516A-EECOT, MBF2M516A-EEEOT, MBF2M516A-
EENOT, MBF2M516C-EECOT and MBF2M516C-EESOT )
P-Series: Minimum 75W or greater system power supply through the PCIe x16
interface and an additional 75W through the supplementary 6-pin ATX power
supply connector (Relevant for OPNs: MBF2H516A-EEEOT
MBF2H516A-EENOT, MBF2H516C-EECOT and MBF2H516C-EESOT).
Airflow Requirements
DPU is offered with one airflow pattern: from the heatsink to the network ports.
Important
The BlueField-2 DPU is designed and validated for operation in data-
center servers and other large environments that guarantee proper
power supply and airflow conditions.
The DPU is not intended for installation on a desktop or a
workstation. Moreover, installing the DPU in any system without
proper power and airflow levels can impact the DPU's functionality
and potentially damage it. Failure to meet the environmental
requirements listed in this user manual may void the warranty.

Nvidia BlueField-2 InfiniBand Specifications

General

Processor	Arm Cortex-A72
Connectivity	InfiniBand, Ethernet
Security	Hardware Root of Trust, Secure Boot
Crypto Acceleration	Yes
Architecture	Arm
PCIe Interface	PCIe 4.0 x16
Security Acceleration	Yes
Network Acceleration	Yes
Network Interface	InfiniBand
Memory	16GB DDR4
Form Factor	PCIe
Product Type	DPU (Data Processing Unit)
Ethernet Speed	200Gbps
Storage	NVMe over Fabric support
Networking Features	RDMA, RoCE, SR-IOV
Cores	8x Arm A72 cores
