NVIDIA BlueField-2 InfiniBand/Ethernet DPU User Guide 61
Non-operational 10% to 90% relative humidity
Regulatory
Safety CB / cTUVus / CE
EMC CE / FCC / VCCI / ICES / RCM
RoHS RoHS compliant
Notes:
(a)
If your target application for this crypto-enabled card will utilize 100Gb/s or higher
bandwidth, where a substantial part of the bandwidth will be allocated for IPsec traffic,
please refer to the NVIDIA BlueField-2 DPUs Release Notes document to learn about a
potential bandwidth limitation. See Related Documents section for details on accessing
the document.
(b)
The BlueField-2 DPUs supplement the IBTA auto-negotiation specification to get
better bit error rates and longer cable reaches. This supplemental feature only initiates
when connected to another NVIDIA InfiniBand product.
(c)
The non-operational storage temperature specifications apply to the product without
its package.
MBF2H516A-EENOT / MBF2H516A-EEEOT Specifications
BlueField-2
DPU
BlueField-2 P-Series - 8 Cores - 550MHz/2750MHz
MBF2H516A-EEEOT
(a)
: Crypto Enabled, Secure Boot Disabled
MBF2H516A-EENOT: Crypto Disabled, Secure Boot Disabled
Important
To power up these FHHL P-Series DPUs, you need to connect a PCIe
external power cable to the onboard 6-pin ATX connector. The
customer should supply the PCIe external power cable (usually
available with the server). Refer to External Power Supply Connector
for pin descriptions.

Nvidia BlueField-2 InfiniBand Specifications

General

Processor	Arm Cortex-A72
Connectivity	InfiniBand, Ethernet
Security	Hardware Root of Trust, Secure Boot
Crypto Acceleration	Yes
Architecture	Arm
PCIe Interface	PCIe 4.0 x16
Security Acceleration	Yes
Network Acceleration	Yes
Network Interface	InfiniBand
Memory	16GB DDR4
Form Factor	PCIe
Product Type	DPU (Data Processing Unit)
Ethernet Speed	200Gbps
Storage	NVMe over Fabric support
Networking Features	RDMA, RoCE, SR-IOV
Cores	8x Arm A72 cores
