17
Display Memory Configuration
Memory-Resolution/Color
The table below is for reference only.
256 color 16bit 32bit
640x480
240Hz 240Hz 240Hz
800x600
240Hz 240Hz 240Hz
1024x768
240Hz 240Hz 200Hz
1152x864
200Hz 200Hz 170Hz
1280x960
170Hz 170Hz 150Hz
1280x1024
170Hz 170Hz 150Hz
1600x900
150Hz 150Hz 120Hz
1600x1200
120Hz 120Hz 100Hz
1920x1080
100Hz 100Hz 85Hz
1920x1200
100Hz 100Hz 85Hz
1920x1440
85Hz 85Hz 75Hz
2048x1536
75Hz 75Hz 60Hz
Monitor Connector Pin Assignments
Pin no. Function Pin no. Function
1 Red Video 9 +5V
2 Green Video 10 Sync Return (ground)
3 Blue Video
11 NC
4 NC
12 DDC DATA
5 Ground
13 Horizontal Sync
6 Red Return (ground) 14 Vertical Sync
7 Green Return (ground)
15 DDC CLOCK
8 Blue Return (ground)
Chapter 6 Technical Information
