Insert your Graphic Card
Remove the cover for the slot you intend to use and save the screw for the mounting
bracket. Then, pick up the Graphic card and position it over the expansion slot
you’ve chosen. Push the card firmly and evenly until it’s fully seated in the slot.
Replace the screw to secure the bracket of the Graphic card to the computer chassis.
Connect the Monitor/DVI (Optional)
Plug your monitor/DVI cable into the monitor/DVI connector on your Graphic card.
Make sure the other end of the monitor/DVI cable is properly connected to your
monitor/DVI.
PCI expansion
slot
Graphics card
Bracket screw
Motherboard
Monitor Connector (Blue)
AGP
expansion slot
DVI Host Receptacle Connector
