NVIDIA GeForce GTX 570 GPU Datasheet
2
o Optimized for OpenCL and DirectCompute
o Full IEEE 754-2008 32-bit and 64-bit precision
o Full 32-bit integer path with 64-bit extensions
o Memory access instructions to support transition to 64-bit addressing
o Improved Performance through Predication
• Improved Memory Subsystem
o NVIDIA Parallel DataCache
TM
hierarchy with Configurable L1 and Unified L2
Caches
o Greatly improved atomic memory operation performance
• NVIDIA GigaThread
TM
Engine
o 10x faster application context switching
o Concurrent kernel execution
o Out of order thread block execution
NVIDIA Technology
• NVIDIA SLI® technology—patented hardware and software technology allows up to
four NVIDIA GeForce GPUs to run in parallel to scale performance and enhance
image quality on today’s top games.
• NVIDIA PhysX™ technology—allows advanced physics effects to be simulated and
rendered on the GPU.
• NVIDIA 3D Vision™ Ready— GeForce GPU support for NVIDIA 3D Vision, bringing
a fully immersive stereoscopic 3D experience to the PC.
• NVIDIA 3D Vision Surround™ Ready—scale games across 3 panels by leveraging
the power of multiple GPUs in an NVIDIA SLI configuration. Combine with 3D Vision
technology for the ultimate 3 panel stereoscopic 3D gaming experience.
GPU Interfaces
• Designed for PCI Express 2.0 ×16 for a peak bandwidth (counting both directions) of
up to 20 gigabytes (GB) per second (PCIe 2.0 devices are backwards compatible
with PCI Express 1.x devices).
• Up to 384-bit GDDR5 memory interface (memory interface width may vary by model)
Advanced Display Functionality
• Two pipelines for dual independent display
• Two dual-link DVI outputs for digital flat panel display resolutions up to 2560×1600
• Dual integrated 400 MHz RAMDACs for analog display resolutions up to and
including 2048×1536 at 85 Hz
• HDMI 1.4a support including GPU accelerated Blu-ray 3D support, x.v.Color, HDMI
Deep Color, and 7.1 digital surround sound. See
www.nvidia.com/3dtv for more
details.
• Displayport 1.1a support
• HDCP support up to 2560×1600 resolution on all digital outputs
• 10-bit internal display processing, including support for 10-bit scanout
• Underscan/overscan compensation and hardware scaling

Nvidia GeForce GTX 570 Specifications

General

GPU Architecture	Fermi
CUDA Cores	480
Core Clock	732 MHz
Memory Size	1280 MB
Memory Type	GDDR5
Memory Interface Width	320-bit
TDP	219 W
Memory Bandwidth	152 GB/s
Max Resolution	2560x1600
Power Connectors	2x 6-pin
DirectX Support	DirectX 11
OpenGL Support	OpenGL 4.1
Bus Interface	PCIe 2.0 x16
Memory Clock	3800 MHz
Texture Fill Rate	43.9 GTexels/s
