Installation and Setup
www.nvidia.com
NVIDIA RTX Blade Server DU-09554-001 _v02|17
a) Raise the lift platform until the unit clears the foam packaging.
b) Move the unit closer to the lift, then move the lift away from the packaging.
c) Lower the platform to safely move the unit to the data center rack.
3.
Move the RTX Blade Server to the rack.
a) Align the system with the rack and raise the lift platform ¼ inch or ~1 cm above
the lip of the rack mount kit.
b) Push the system into the rack ¾ of the way before it falls off the platform.
c) Lower the platform so the system is no longer resting on it.
d) Finish pushing the system into the rack until the ears are flush with the rack
posts.
4.
Complete the installation by tightening the four captive screws on the front of the
RTX Blade Server to secure the unit to the rack.
