Nvidia RTX BLADE SERVER User Manual

Introduction to the NVIDIA RTX Blade Server
www.nvidia.com
NVIDIA RTX Blade Server DU-09554-001 _v02|2
1.1.Hardware Specifications
1.1.1.Components
System Overview
Component Qty Description
Blades 10 Hot-pluggable. Each blade contains two independent nodes.
Power Supply 10 5+5 redundancy 2200 W each.
Management Module 1 Chassis level BMC functionality (CMC/CMM).

Aggregate 1Gb management port from each node to 2x 1Gb uplinks
Network Modules Aggregate 2x 10Gb from each node to 4x 40Gb uplinks
Per Node Specifications
Component Qty Description
CPU 1 Intel Core i9-based CPU
GPU See
description
NVIDIA RTX GPU: 2x 150W Single Width GPU
NVIDIA CUDA Cores: 3,584
Memory: 16 GB GDDR6
Network 1 Dual 10 Gb NIC
Storage (OS) Drive 1 500 GB M.2 SSD
System Memory 2 16 GB DDR4 UDIMM (32 GB total per node)
Mechanical
Feature Description
Form Factor 8U Rackmount
Dimensions
17.6” (447 mm) W x 31.3” (795 mm) D x 13.82” (351 mm) H
Gross Weight 300 lbs
