NVX MVPA4 User Manual

Visit: nvx.com | Call: 213.444.1689 | 15303 Ventura Blvd. 9th Floor, Sherman Oaks, CA 91403
2
AMPLIFIERS
SPECIFICATIONS
FEATURES
Model Number
MVPA1 MVPA4
RMS Power Output @ 14.4
200 Watts x 1 Ch @ 4 Ohm
300 Watts x 1 Ch @ 2 Ohm
50 Watts x 4 Ch @ 4 Ohm
100 Watts x 4 Ch @ 2 Ohm
Bridged 175 Watts x 2 Ch @ 4 Ohm
Frequency Response 10 Hz - 400 Hz 10 Hz - 20 kHz
Input Sensitivity 0.20 V - 5 V 0.20 V - 5 V
Signal-to Noise Ratio 105 dB 101 dB
Variable Lowpass Filter 40 Hz - 400 Hz 40 Hz - 400 Hz
Variable Highpass Filter – 40 Hz - 4 00 Hz
Bass Boost 0 / +6 / +12 dB –
Total Harmonic Distortion < 0.65 % < 0.07 %
Operating Voltage 8 V - 16 V 8 V - 16 V
Net Weight 2 lbs (0.90 kg) 2 lbs (0.90 kg)
A Height
1.56 in (39 mm) 1.56 in (39 mm)
B Length
5.44 in (138 mm) 5.44 in (138 mm)
C Width
4 in (102 mm) 4 in (102 mm)
A
B
C
MVPA1
• Monoblock 1-Channel Amplier
• Micro Class-D Circuitry
• LED Power/Protection Indicators
• 15A x 2 Mini-Blade Fuse
• Operating Voltage: 8V - 16V
• All Specs at Rated Power
MVPA4
• 4-Channel Bridgeable Amplier
• Micro Class-D Circuitry
• LED Power/Protection Indicators
• 30A x 1 In-Line Mini-Blade Fuse
• Operating Voltage: 8V - 16V
• All Specs at Rated Power
RMS Power Output: 200 Watts x 1 Ch @ 4 Ohm 1% THD+N
Signal-to Noise Ratio: 82 dB (reference: 1 Watt @ 4 Ohm)
RMS Power Output: 50 Watts x 4 Ch @ 4 Ohm 1% THD+N
Signa-to Noise Ratio: 84 dB (reference: 1 Watt @ 4 Ohm)
