Nytech DS-8310 Introduction
8 - English
Controls and buttons
This User manual has a fold-out cover. On the inside of the cover the
camera is shown with the meanings of the controls and buttons.
Figure of back
1 Stabilizer
2 On/Off button (Power)
3 Shutter
4 Zoom button
5 Playback button (Play)
6 Menu button
Figure: Four-way button
7 Four-way button for Menu navigation
(see right)
8 Eyelet for carrying strap
9 SET button
10 USB and AV port
11 Camera mode button
12 Delete/ASM
13 Display
Figure of front
14 Flash
15 Self-timer lamp and auto focus lamp
16 Speaker
17 Lens
18 Microphone
Bottom
19 Tripod mount
20 Battery compartment cover
and memory card slot
19 20
