THREE VIEW DRAWING
■
■
■
■
■
■
8.56cc (0.523cu.in.)
23.0mm (0.906in.)
20.6mm (0.811in.)
2,300
~
13,000r.p.m.
0.9bhp/12,000r.p.m.
434g (15.31oz.)
Dimension(mm)
Specification
Displacement
Bore
Stroke
Practical R.P.M.
Power output
Weight
26
