O&M D3250 - Control Panel Layout

D 3250
Control Panel layout.
240v Terminals
240v Breaker
24VDC Power supply
PLC
Inverter
Loop Detector
Low voltage terminals
24v Fuse 1Amp
Programming
screen
Above shows a typical barrier control panel layout which identifies the major components
