D
3250
Technical data.
Geared Motor Spec:
Type: Worm & Wheel
Overall speed: 2 rpm
Max rated torque: 1050nm
Actual torque: 1000nm
Gearbox efficiency: 40%
Output size: 42mm
Mounting position: V5
Angular Backlash: 15' +/- 5' / 0.00436
+/- 0.00145 (W110)
Lubricated with: Shell Omala 1.7 litres
(W110)
Electric Motor:
400v 50hz 3 phase
6 pole
IP55
8mm End Cap
B14 C face mounted
Frame size 80
Output power: 0.55kW
Current @ 400v: 1.70A
Rated speed: 885rpm
Full-load power factor(cos): 0.72
Full-load efficiency: 65%
Locked rotor current is/in: 4.7
Locked rotor torque Ms/Mn: 2.0
Break down torque Ms/Mn: 2.1
Net weight 9.2kg
Driving end bearings: 62042RS/C3
Maximum Boom Length: 7.0 metres
Power Requirement: 230v, Single Phase, 50Hz, 5 Amps
Drive Motor: 3 Phase motor & wormed gearbox
Opening/Closing time: 1.5 - 7.0 seconds
Duty Cycle: 100% continuos duty rating
Operation Time: 8 Seconds per metre (Variable)
Finish: Polyester Powder Coated
Dimensions: 420mm x 405mm x 1138mm
Access Controls: Push-button, Proximity cards, card readers,
tokens, voice/video intercoms, keypads and remote fobs.
Specification
Motor/Gearbox
Optional extras:
? Folding bottom skirt up to 6.0m
? Hi-Bar skirt up to 5.0m
? Articulated arm (low ceilings)
? Pogo tip support
? Boom lights
? Magnetic lock
? Lorry height stop/no entry signs
? Warning sounder/flashing Beacon
? Sensing safety edges
Accessories
Made in the UK
GB
2003/108/CE Directive
for waste electricaland
electronic Equipments
DISPOSE OFPROPERLY
ENVIRONMENT-NOXIOUSMATERIALS
Made using
recycled
paper
Dimensions
