2 Information about these operating instructions
Welcome to OASE Living Water. You made a good choice with the purchase of this product BioTec Screen-
Matic² 40000/60000/140000.
Prior to commissioning the unit, please read the instructions of use carefully and fully familiarise yourself with
the unit. Ensure that all work on and with this unit is only carried out in accordance with these instructions.
Adhere to the safety information for the correct and safe use of the unit.
Keep these instructions in a safe place! Please also hand over the instructions when passing the unit on to a
new owner.
2.1 Symbols used in these instructions
2.1.1 Warnings
GB
The symbols used in this operating manual have the following meanings:
Risk of injury to persons due to dangerous electrical voltage
This symbol indicates an imminent danger, which can lead to death or severe injuries if the appropriate
measures are not taken.
Risk of personal injury caused by a general source of danger
This symbol indicates an imminent danger
, which can lead to death or severe injuries if the appropriate
Important information for trouble-free operation.
2.1.2 Additional information
A Reference to a figure, e.g. Fig. A.
→ Reference to another section.
3 Product Description
3.1 Unit configuration
ScreenMatic rotating screen unit
Sensor underneath the control device
– When the sensor comes into contact with the water on the ScreenMatic screen, an automatic cleaning process is triggered.
Stripper
– scrapes the debris from the ScreenMatic screen and conveys it into the debris tray.
"Max. water jet" mark
– Debris may be washed out of the debris collection tray if the water jet from the water distributor exceeds this mark.
Transformer
– Voltage supply for the control device and motor
Motor
– Drive of the ScreenMatic rotating screen unit
