OASIS Technical Bulletin OAS036RevC

Kalix – Expansion Tank Installation

090805 2 of 4 OAS036RevC

3. Assemble expansion tank:

a. Attach fitting and reducer “B” to expansion tank “A”. Connect the two lengths of blue tube to the Tee-piece.

Connect the longer length of tubing to the fitting attached to the expansion tank

b. Fit expansion tank assembly to the mounting bracket

2.a

2.b

2.c

3.a

3.b
