4. Product parameters and accessories
4.2 Product accessories
4.3 Support Agreement:
4.1 Product parameters
3
4.
5.
6.
ESC to return.
Press the button to the left or next page
Green light: support the vehicle detection
Yellow light: It is read that the vehicle is faulty
Red light: The product is energized normally
Working voltage: DC9～16V
Working current: about 50mA
Operating environment: -20～65℃
Storage temperature: -30～80℃
Dimensions: 168*89*25mm
Eight languages: English, German, Italian, Dutch, French, Spanish,
Chinese, Russian.
Accessories Host *1 Manual *1
1. SAE J1850 PWM (41.6Kbaud)
2. SAE J1850 VPW (10.4Kbaud)
3. ISO9141-2(5 baud init, 10.4Kbaud)
4. ISO14230-4 KWP (5 baud init, 10.4 Kbaud)
5. ISO14230-4 KWP (fast init, 10.4 Kbaud)
6. ISO15765-4 CAN (11bit ID, 500 Kbaud)
7. ISO15765-4 CAN (29bit ID, 500 Kbaud)
8. ISO15765-4 CAN (11bit ID, 250 Kbaud)
9. ISO15765-4 CAN (29bit ID, 250 Kbaud)
