9. TUBES
9.1. Tube layout
power supply
board
line-
board
phono MC-
board
Before opening the cover it is mandatory to remove the power cord
from the mains power inlet.
tubes used also available under this discription
Line board
ECC 82 (E 82 CC / ECC 802 S / 12 AU 7 / 5814 A)
ECC 88 (6 DJ 8 / E 88 CC / 6922)
Phono MC board
ECC 81 (E 81 CC / ECC 801 S / 12 AT 7 / 12 AT 7 WA)
