OdorStop OS36 - Installation Guide; Mounting Location Selection

INSTALLATION
How To Install Your OdorStop UV Air Treatment System
Ifyourheating/cooling(HVAC)systemisequippedwithair
conditioning,itisrecommendedthattheUVAirTreatment
System (unit) be mounted directly above the cooling coil. The
OS36/OS72 can prevent the growth of a high percentage
of micro-organisms such as mold, bacteria and viruses on
surfaces such as cooling coils, drain pans and duct work.
Selecting Mounting Location
1. The unit can be mounted in any orientation, but should be
mountedinawaythattheLEDindicatorlight(s)canbeseen.
2. Choose a location that will make changing/cleaning of the
UVbulb(s)easy.
3.InstallunitonaatsurfaceoftheductworkABOVEtheair
conditioningcoolingcoil(“ACoil”)ifyourHVACsystemhas
airconditioning.IfyourHVACsystemdoesnothaveair
conditioning, the unit should be installed on the supply air
duct if possible. The unit can be installed on a return air duct
if necessary.
CAUTION: DONOTinstalltheunitinthe“Acoil”orunder
ahumidierasdamagemayoccur.Ifyouareunsureif
youhavechosenacorrectmountinglocation,refertoyourHVACsystem’sownersmanualorcalla
qualiedprofessionalforassistance.
4.Selectamountinglocationthathasaminimumdepthof17inches.TheUVbulbis16incheslongand
must have adequate clearance.
5.BesuretolocatetheunitawayfromanyplasticorrubbercomponentsthatmaybedamagedbyUV
light. If mounting options are limited, plastic and rubber may be covered with aluminum foil duct tape in
ordertoprotectthemfromtheUVlight.
6.Theunithasa6footlongpowercordandmustbeinstalledwithinreachofa120Voltgroundedpower
outlet.Haveaqualiedprofessionalinstallaproperlygroundedpoweroutletifthereisnotonewithin
range of the power cord.
Included:
•UVUnit
•4SheetMetalMountingScrews
•UVlamp(s)-1forOS36,2forOS72
•SpareFuse
•InstructionManual
Tools Required For Installation:
•Drill
•1/4”NutDriver
•3/32”DrillBit
•21/2”MetalCuttingHoleSaw
