Battery Charging
Fault Isolation
Failure Possible Cause Remedy
Battery charger inoperative The Workstation disconnected from AC line
or the AC line goes down.
Check AC connections to Workstation
The Workstation Interconnect Cable
disconnected from the C-Arm.
Check Interconnect Cable
A fuse blows or the Battery Charger fails. Replace fuses (see AC and DC power
chapters of this manual.
Instantaneous peak battery charging
current exceeds 15.5 amps, causing an
Overcurrent shutdown of the Battery
Charger.
Power down or CHG_DISAB will reset the
fault latch and allow normal operation. Check
for shorts at the battery charger output. -MW
Output voltage exceeds 250 Volts, causing
an Overvoltage shutdown of the Battery
Charger.
Power down or CHG_DISAB will reset the
fault latch. Check that the CB1 circuit breaker
is turned on.
The X-Ray Controller asserts the
CHG_DISAB signal to turn the Battery
Charger off
This is a normal function during the
precharging period and whenever the
Codonics printer is operating.
4
