Calibration
Iris Stop
Closed I ris stop
set screw
Closed Iris Stop Set Screw
Lens Focus
Focus Verification
1. Attach a resolution tool to the face of the focus grid near the center at a 45º angle (see drawing, Beam Alignment section,
previously in this chapter).
2. Turn off Auto Histo.Use brightness and contrast adjustments to view resolutions.
3. Verify that the following minimum resolutions can be seen in the image:
68
