Calibration
II Size Minimum Resolution
9 Normal Field 2.3 LP/MM
9 Mag 1 3.2 LP/MM
9 Mag 2 3.8 LP/MM
12 Normal Field 1.7 LP/MM
12 Mag 1 2.3 LP/MM
12 Mag 2 3.0 LP/MM
Focus Adjustment
1. Attach a resolution tool to the face of the focus grid near the center at a 45º angle.
2. Carefully loosen the Lens Focus Set Screw.
3. Adjust the focus using the Lens Iris Focus Lever.
Note: On some systems you may have to slightly loosen the Lens Iris Focus Lever to get it to move.
4. Retighten the Lens Focus Set Screw (and Lens Iris Focus Lever---see following picture).
69
