Replacement
High Voltage and Control Cable Signals
Runs
From
Connector
On
Assembly
To
Connector
On
Assembly
Purpose
A1P8 Backplane P8 CCD
Camera
Camera Communications
(Manchester serial)
A11J7 Power/Signal
Interface
PCB
P8 CCD
Camera
Power to Camera
A4J5 Power/Motor
Relay PCB
J15 X-ray Tube Stator Run Voltages
J3 Camera P1 Interconnect
Cable
Connector
J1
Video to Workstation
J4 Camera P1 Interconnect
Cable
Connector
Pilot Tone sync signal to Workstation
ANODE HV Tank ANODE X-ray Tube High Voltage positive with respect to
Ground.
CATHODE HV Tank CATHODE X-ray Tube High Voltage Negative with respect to
Ground.
A1J10 Backplane J15 X-ray Tube Housing Temperature analog signal
from X-ray Tube
61
