Replacement
Image Intensifier and Power Supply
The Image Intensifier and its DC power supply mount on the C weldment opposite the X-ray tube as shown in the following
illustration.
Camera Cover
EMI Shield
CCD Camera
Image Intensifier
Image Intensifier Location
Follow these steps to replace the Image Intensifier assembly.
1. Turn the Workstation off and remove its power cord from the AC outlet.
72
