VGA Video Card
ISA Bus Slot 4 in the Host Pentium CPU motherboard is normally vacant and unused. It can, however, accommodate
a VGA video card that may be used for diagnostic purposes.
IDE Hard Disk Drive
The Workstation normally boots from the 50-megabyte non-DOS partition of this 4.3-Gigabyte drive, which contains
the Nucleus® operating system and OEC application software. This drive also has a DOS-readable partition that is
available to the user for image and data storage. The IDE hard disk drive is located in the bottom right-hand corner of
the Electronics box.
