Replacement
Power Panel Removal
Rear Wheels and Brakes
To remove the Rear Wheel Assembly perform the following:
1. Remove two screws from the End Cap Cover and remove the End Cap.
2. Jack up the Wheel Axle approximately 2 - 2.5 inches.
3. Loosen one of the turnbuckles on the steering chain.
113
