OEC UroView 2800 - ABS Path

OEC UroView
®
2800 Table/Generator Functional Block Diagrams
55
Service Periodic Maintenance
Contents
Schematics Illustrated Parts Installation
Page 2 of 2
1A
Interconnect
Plug
Back
Plane
1
KVp and mA changes are sent to the generatorvia the CAN Bus.
Camera Gain control is sent through the Manchester communications to the CCD camera..
See KV and MA Functional Diagrams.
2
Table/Generator
Interface PCB
CCD
Camera
Intensifier
XRAY Tube
Generator
2
P3
Cam_Comm+
Cam_Comm-
P8
ISA


Arcnet
Node
11
P1
P3
2
1
Arcnet_HI
Arcnet_LO
8
7
ABS Path
Control Path
07/01
2800
GE OEC Training
