OEC UroView 2800 - Page 82

OEC UroView
®
2800 Table/Generator Functional Block Diagrams
82
Service Periodic Maintenance
Contents
Schematics Illustrated Parts Installation
M6+
M6-
X1
X5
6
7
8
3
4
5
Table Board-Digital
(under the table)
1
2
X4
1
2
3
4
2
21
22
23
MOTOR
(M6)
PWM
1A
1B
g
Page 2 of 3
03/02
GE OEC Training
Uroview 2800
TBL_LAT.DS4
S16
S17
S18
R6
1C
1D
Accessory
Switches
+24V
ZUBH_OK
VERLAENG
MIKTION
Table
Extension
Micturation
Seat
Accessory OK
S16 S18 S17
M6R6
Motor Drive Diagram
Table Lateral (M6) & Accessory Switches
Motor Drive Diagram – Table Lateral
