Operating Instructions and Parts Manual 24385
USB VIDEO BORESCOPE
the scope of this manual to properly describe the
correct procedure and test data for each vehicle.
• Always perform vehicle service in a properly ventilated
area. Never run an engine without proper ventilation
for its exhaust. Stop work and take necessary steps
to improve ventilation in the work area if you develop
momentary eye, nose, or throat irritation as this
indicates inadequate ventilation.
• Engine parts that are in motion and unexpected
movement of a vehicle can injure or kill. When working
near moving engine parts, wear snug fit clothing and
keep hands and fingers away from moving parts.
Keep hoses and tools clear of moving parts. Always
stay clear of moving engine parts. Hoses and tools
can be thrown through the air if not kept clear of
moving engine parts. The unexpected movement of
a vehicle can injure or kill. When working on vehicles
always set the parking brake or block the wheels.
• Avoid accidental fire and/or explosion. Do not smoke
near engine fuel and battery components.
• The warnings, precautions, and instructions discussed
in this manual cannot cover all possible conditions
and situations that may occur. The operator must
understand that common sense and caution are
factors which cannot be built into this product, but
must be supplied by the operator.
• For safety purposes and the prevention of damage
to expensive components it is advised that the user
have an understanding of basic automotive repair and
a working knowledge of automotive systems.
• We believe the information contained herein to be
reliable. However, general technical information is
given by us without charge and the user shall employ
such information at his own discretion and risk. We
assume no responsibility for results or damages
incurred from the use of such information in whole or in
part. Always refer to specific instructions and technical
information supplied by vehicle manufacturer.
• The manufacturer declines any and all responsibility
for damage to vehicles or components if said damage
is the result of unskillful handling by the operator or of
failure to observe the basic safety rules set forth in the
instruction manual.
DISPOSAL
At the end of the useful life of the Video Borescope,
dispose of the components according to all state,
federal, and local regulations
PURPOSE
This digital Video Borescope is an ideal tool for
inspecting difficult-to-reach areas normally hidden
from sight. The ergonomic USB Video Borescope
features a camera probe and USB connection to view
images and video on your computer. The multipurpose
Borescope is suitable for internal inspection of cylinder
bores and vehicle compartments/components. Ideal
for the inspection of engines, machinery, buildings and
infrastructure.
07/14
2014 ©OEM-TOOLS
Digital Image Sensor
1/6” CMOS
Resolution
640 (H) x 480 (V)
Viewing Angle
56°
Focus
6 cm
Input Interface
USB 2.0
S/N Ratio
46 dB
White Balance
Auto
Picture Format
JPEG, BMP
System Requirements
Windows® XP/Vista/
Windows 7/Mac OS,
USB port
IP Rating
IP66 (camera + flexible
tube)
Power Supply
5 VDC via USB port
Dimensions
Camera 14 x 72 mm,
Flexible tube 54 cm,
USB cable 200cm
Operating Temperature
32°F - 113°F
PRODUCT SPECIFICATIONS
