CITOMIG 200MP

EN INSTRUCTIONS FOR USE AND MAINTENANCE

FR INSTRUCTIONS D’UTILISATION ET DE MAINTENANCE

DE BEDIENUNGS- UND WARTUNGSANLEITUNG

IT MANUALE D’USO E MANUTENZIONE

ES INSTRUCCIONES DE USO Y MANTENIMIENTO

PT INSTRUÇÕES DE UTILIZAÇÃO E MANUTENÇÃO

NL INSTRUCTIES VOOR GEBRUIK EN ONDERHOUD

SV ANVÄNDAR- OCH UNDERHÅLLSINSTRUKTIONER

Cat. nr. : 8695-8030

Rev. : A

Date : 11/2013

www.oerlikon-welding.com

PL 

RO 

RU



SK 

DK BRUGS- OG VEDLIGEHOLDELSESANVISNING

CZ 

NO INSTRUKSJONER FOR BRUK OG VEDLIKEHOLD

MULTIPROCESS POWER SOURCE

GÉNÉRATEUR MULTI-PROCÉDÉS

MULTIPROZESS STROMQUELLE

GENERATORE MULTIPROCESSO

FUENTE DE ALIMENTACIÓN MULTIPROCESO

FONTE DE ALIMENTAÇÃO MULTIPROCESSO

MULTIPROCES VOEDINGSBRON

MULTIFUNKTIONELL SVETSSTRÖMKÄLLA

WIELOPROCESOWE ŹRÓDŁO ZASILANIA

SURSĂ DE PUTERE MULTIPROCES

МНОГОЗАДАЧНЫЙ ИСТОЧНИК ПИТАНИЯ

MULTIPROCESNÝ ZDROJ

MULTIPROCES STRØMKILDE

MULTIPROCESNÍ ZDROJ NAPÁJENÍ

MULTIPROSESS STRØMKILDE

Table of Contents

Questions and Answers

K
Kimberly Edwards DDSAug 18, 2025
Why is there a lack of penetration in my Oerlikon W000377723 Welding System?
- N
  Nicole LoveAug 18, 2025
  Lack of penetration can occur due to several reasons: * The voltage or wire feed speed might be too low, so readjust the welding parameters. * A loose connection inside the machine may exist; in this case, clear with compressed air and tighten all connections. * The contact tip could be worn or the wrong size, so replace the contact tip. * There might be a loose gun connection or faulty gun assembly, so tighten or replace the torch. * Using the wrong size wire can cause this issue, so use the correct size welding wire. * If the torch is moved too fast, slow down and move the gun smoothly.
A
Angel WebbAug 21, 2025
What to do if wire burns back to contact tip on Oerlikon W000377723 Welding System?
- J
  jasonbarkerAug 21, 2025
  If the wire burns back to the contact tip, consider these potential causes: * The contact tip might be clogged or damaged, so replace it. * The wire feed speed may be too slow, so increase it. * You might be using the wrong size contact tip, so use the correct size. * There could be a bad connection from the cable to the clamp, so tighten the connection or replace the cable. * Slag buildup inside the nozzle, or a shorted nozzle, may be the culprit, so clean or replace the nozzle.
D
davisalexanderAug 23, 2025
How to fix wire birdnesting at the drive roller on Oerlikon W000377723 Welding System?
- K
  Kimberly MurrayAug 23, 2025
  Wire birdnesting at the drive roller can be caused by: * Excessive pressure on the drive roller, so adjust the pressure. * A worn or damaged gun liner, so replace the wire liner. * A clogged or damaged contact tip, so replace it. * A liner that is stretched or too long, so cut the wire liner to the right length.
K
Karen SpearsAug 26, 2025
Why is my Oerlikon W000377723 producing poor quality welds?
- E
  Elizabeth BrownAug 26, 2025
  Poor quality welds can result from: * Insufficient gas at the weld area. Check that drafts are not blowing the gas away; if so, move to a more sheltered area. Also, check the gas cylinder contents gauge, regulator setting, and gas valve operation. * A rusty, painted, damp, oily, or greasy workpiece. Ensure the workpiece is clean and dry. * Rusty or dirty wire. Ensure the wire is clean and dry. * Poor ground contact. Check the ground clamp/workpiece connection. * An incorrect gas/wire combination. Check the manual for the correct combination.
J
Judy HallAug 27, 2025
What to do if wire pushes torch back from the workpiece with Oerlikon W000377723?
- S
  Sandra OsbornAug 27, 2025
  If the wire is pushing the torch back from the workpiece, consider these possible causes: * The torch may be held too far from the workpiece, so hold it at the right distance. * There could be a bad connection between the earth clamp and the workpiece, so clean and deoxidize the contact area of the earth clamp. * The workpiece may be excessively oxidized or painted, so brush the point to be welded carefully.
S
samuel38Aug 30, 2025
What to do if the fan operates but there is no wire feed, weld output or gas flow on Oerlikon W000377723?
- C
  Cynthia LopezAug 30, 2025
  If the fan operates normally, but there is no wire feed, weld output, or gas flow when the gun trigger is pulled, the following could be the cause: * A faulty trigger on the gun, so replace the torch trigger. * Thermostat intervention. Allow the welder to cool. The extinguishing of the pilot lamp / switch on the front panel indicates the thermostat has closed.
F
fmackSep 1, 2025
Why does my Oerlikon Welding System workpiece clamp and/or cable get hot?
- N
  nicolewillisSep 1, 2025
  If the workpiece clamp and/or cable gets hot, it may be because the wire feed speed is too fast. Decrease the wire feed speed.
B
bradfordjeremySep 3, 2025
How to troubleshoot if feed motor operates but wire will not feed on Oerlikon W000377723?
- L
  lopezjacobSep 3, 2025
  If the feed motor operates but the wire won't feed, consider these possibilities: * A faulty wire feeding motor (though rare), so replace it. * Insufficient feed roller pressure, so increase the roller pressure. * A burr on the end of the wire, so recut the wire square with no burr. * A blocked or damaged liner, so clear it with compressed air or replace it.
S
sharonhartmanSep 6, 2025
What causes the gun nozzle to arc to the work surface on Oerlikon Welding System?
- Z
  zmaysSep 6, 2025
  If the gun nozzle arcs to the work surface, it is likely because the nozzle is clogged, so clean or replace the nozzle.
F
Felicia PerezSep 8, 2025
Why is my weld deposit stringy and incomplete with my Oerlikon W000377723?
- A
  adkinsjoseSep 8, 2025
  A stringy and incomplete weld deposit can be due to: * Moving the torch over the workpiece too quickly, so move the torch slower. * An incorrect gas mixture, so consult the shielding gas table.

Summary

GENERAL INFORMATION AND START-UP

Unit Overview and Specifications

Details the CITOMIG 200MP's features, components, and technical data.

Initial Setup and Panel Controls

Covers front panel presentation and basic setup menu adjustments.

WELDING PROCESS CONFIGURATION

MMA and TIG Welding Setup

Guides for connecting and configuring MMA and TIG welding processes.

MIG;MAG Welding Setup

Comprehensive guide to MIG/MAG modes, parameters, and synergy settings.

OPERATIONS AND SUPPORT

Optional Accessories and Installation

Information on trolley and spool kit, including installation steps.

Faults, Troubleshooting, and Maintenance

Covers error messages, problem-solving, and routine upkeep.

TECHNICAL DETAILS

Spare Parts List

Comprehensive list of replaceable components with reference numbers.

Wiring Diagram

Schematic illustrating the unit's electrical connections and components.

Oerlikon W000377723 Specifications
