ELECTRICAL
SHORE POWER CHARGING
To charge via shore power, simply plug a standard 15-amp
power cord into the exterior mounted shore power port and
plug in electrical power source.
NOTE: The base unit is NOT equipped with an on board solar
charge controller.
REPLACEMENT & MAINTENANCE OF LIGHTS
All interior and exterior lights are LED xtures rated to provide
issue free service for the life of the trailer. The LEDs in these
xtures are not serviceable, and the xture must be replaced if
malfunctioning by a qualied RV technician.
NOTE: External light xtures may require seasonal maintenance
to prevent corrosion.
Ref. Fig 5.1, 5.2, 5.3, 5.4, 5.5, 5.6
ELECTRICAL SYSTEM
(where equipped)
ELECTRICAL SYSTEM – ALL MODELS
WIRING DETAILS
The following details of each unit’s color coded wiring layout is
intended to aid only authorized RV technicians to troubleshoot
and repair any wiring problems that could potentially arise
and is not intended to aid the owner in doing any electrical
repairs.
WIRED
(not connected at factory)
Tow vehicle to trailer battery connection requires electrical
installation and modication of the 12V trailer pin by an
authorized RV technician or Automotive Technician. The
manufacturer is not responsible for any damage caused to the
tow vehicle through electrical modication.
