Maintenance
1. Your OFITE Portable Roller Oven has been preset at the factory to
operate at either 115V (174-00) or 230V (174-00-1). However, this
product is designed to be easily converted from 115V to 230V and vice
versa. To accomplish this:
Disconnect the unit from the power source before opening the unit
casing.
a. Remove the right-hand side panel (nearest the controls).
b. Remove the existing plug receptacle and replace it with the new one.
For 115V, use part no. 165-47. For 230V, use part no. 164-30.
Plug
Recepticle
Speed Control
Knob
Circuit Board
Voltage
Conversion
Switch
Speed Control
Knob
Voltage
Conversion
Switch
To Next Page
