The OFNEX N17 True Wireless Earbuds are a pair of Bluetooth earbuds designed for audio playback and calls, featuring a compact design and a charging case with a digital power display.

Function Description:

The N17 earbuds are designed for wireless audio streaming and hands-free calling. They support various Bluetooth profiles including AVRCP, HFP, HSP, and A2DP, ensuring compatibility with a wide range of devices. The earbuds feature a multi-function button (MFB) on each earbud for controlling playback, calls, and voice assistance. The charging case not only protects and charges the earbuds but also provides a digital display of its remaining battery percentage. The earbuds themselves have LED lights to indicate their charging status.

Important Technical Specifications:

Model Name: N17
FCC ID: 2A9T5-N7
Bluetooth Version: V5.3
Supported Profiles: AVRCP/HFP/HSP/A2DP
Headphones Battery Capacity: 45mAh
Charging Case Battery Capacity: 3.7V 400mAh/1.48Wh
Input: 5V-1A
Charging Time: Approximately 2 hours for the charging case.
Transmission Range: ≤33 feet (without obstacle)
Wireless Charging Support: Yes (charging pad not included)
Charging Port: USB-C

Usage Features:

Power On/Off & Pairing:

Automatic Power On/Off & Pairing:
- To power on and enter pairing mode, simply open the lid of the fully charged charging case. The earbuds will automatically power on.
- For first-time pairing, activate Bluetooth on your phone, search for "N17," and connect.
- For subsequent use, opening the lid of the charging case will automatically connect the earbuds to your previously paired device.
- To power off and disconnect, place the earbuds back into the charging case and close the lid.
Manually Power On/Off:
- If the earbuds are out of the charging case and off, press and hold both earbuds for 2 seconds to power them on.
- To manually power off, disconnect Bluetooth on your device, then press and hold either earbud for 5 seconds. Both earbuds will flash red and power off.
- The earbuds will automatically power off if not connected to a device for over 5 minutes.

Pairing with Other Devices:

To pair with a new device, disconnect "N17" from the last paired device, then search and connect "N17" on the new device.
Alternatively, press the reset button on the charging case for 5 seconds to reset the earbuds, then search and connect "N17" on the new device.

Mono Mode:

You can use one earbud independently while the other remains in the charging case.
To enter mono mode from dual mode, place one earbud into the charging case.
Alternatively, take only one earbud out of the charging case, then search and connect "N17" on your device.
In single mode, L/R earbuds only support playing the next song and cannot control volume.

Call Control:

Answer Call: Tap (L/R) earbud once.
End Call: Tap (L/R) earbud once.
Reject Call: Long press (L/R) earbud for 2 seconds.

Voice Assistance:

Activate Siri (or other voice assistant): Tap (L/R) earbud thrice.

Music Mode Control:

Play/Pause: Tap (L/R) earbud once.
Next Track: Tap R earbud twice.
Last Song: Tap L earbud twice.
Volume+: Press & hold R earbud.
Volume-: Press & hold L earbud.

Charging:

Charging Earbuds: Remove the protective film from the earbuds, then insert them correctly into the charging case. They will automatically start charging.
Charging Case (USB-C): Use the provided Type-C cable with a 5V/1A adapter (not included) to charge the case. A USB-C charging cable is included in the packing box.
Wireless Charging: Place the charging case on a wireless charging pad (not included). It is recommended to use a wireless charging pad with a QI certificate.

LED Power Display:

The charging case displays the remaining battery percentage from 0-100. "0" indicates the case needs charging, while "100" means it's fully charged.
The earbud charging indicator flashes down and up when an earbud is charging and stops flashing when fully charged.
Earbud's LED light: Red light indicates "being charged," and the red light turning off means "fully charged."

Factory Restore Setting (Reset):

When to reset: If only one side plays music, if "N17" cannot be found on the device, or if both earbuds fail to pair with each other or experience connection issues.
How to reset:
1. Delete all "N17" entries from your phone's Bluetooth settings and deactivate Bluetooth.
2. Place both earbuds in the charging case.
3. Long press the Reset Button on the bottom of the charging case for about 5 seconds. The LED display will flash 3 times, indicating a complete reset.
4. Pick up the earbuds, activate Bluetooth on your device, and select "N17" to connect.

Sync Volume on Android:

If the volume is too low, access developer options on your Android device and enable "absolute volume" to utilize the full capabilities of the earbuds.

Maintenance Features:

Caution & Cleaning:

Protective Film: Before first use, remove the protective film from the earbuds, otherwise, they will not charge.
Charging Contacts: If the headphones cannot be charged, clean the magnet charging contact on the earbud and the charging pin on the charging case with alcohol wipes.
Protective Grille: If the sound becomes low, clean the protective grille of both earbuds.

Wearing Correctly:

Choose suitable ear tips and wear the earbuds correctly to enhance sound quality. The manual provides illustrations for correct and incorrect wearing.

Customer Service:

Email: support@ofnex.com
Phone: (857) 688-5733
Web: www.ofnex.com
OFNEX offers support to solve product problems within 24 hours.

OFNEX N17 - Product Overview
